Rectangular Proximity Sensor 80mm, PNP NO/NC, Upper Sensing Type – AS80-50DP3

Autonics Rectangular Inductive Long-Distance Proximity Sensor – AS80-50DP3

PNP Normally Open + Normally Closed, Cable type connection, 4-wire

The Autonics Rectangular proximity sensor AS80-50DP3 features outstanding noise protection and stable sensing performance due to its specialized sensor IC developed by Autonics. This best proximity sensor comes in a Rectangular shape, sensing distance of 50mm, sensing side diameter and frame size 80mm and rectangular installation. The standard rectangular inductive sensor can be used in diverse applications requiring non-contact detection of metallic objects.

As a quick report, this inductive long-distance provides:

• 80 mm frame size

• PNP Normally Open + Normally Closed control output

• 50 mm sensing distance

• Rectangular installation

• Improved noise resistance with dedicated IC

• Surge protection circuit, output short over current protection circuit, reverse polarity protection

• IP67 ingress protection structure according to IEC standards

• Power indicator (green), operation indicator (yellow)

• Power supply: 12 – 48 VDC (operating voltage: 10 – 65 VDC)

• ≤ 15 % of sensing distance Hysteresis

• 30 Hz Response frequency

Body

This inductive long-distance proximity sensor’s case is made of PC + ABS.

The AS80-50DP3 features IP67 ingress protection.

The red LED on its body acts as the operation indicator and green LED power indicator.

Connection

The Autonics proximity sensor AS80-50DP3 features standard cable type connection. This cable covers the sensor’s 4 wires. It is 5 mm in diameter and 2 meters in length.

Sensing specifications

This inductive sensor’s frame size is 80mm. The maximum distance that this sensor can detect its standard sensing target, which is a 150×150×1 mm piece of iron, is 50 mm. This so-called sensing distance differs from one sensing target to another, based on their material, size, etc.

Although almost no one talks about the setting distance of an inductive sensor, it is a big deal to know this concept. Every sensor can detect its standard sensing target in a specified range, no matter what changes occur in ambient temperature, voltage fluctuations, etc. This distance, which is called the setting distance, is from 0 to 35 mm for this proximity sensor.

Control output

The AS80-50DP3 features PNP Normally Open + Normally Closed control output.

Temperature

There are limitations in temperature and humidity in which AS80-50DP3 proximity sensor is used:

• Storage temperature: -30 … 80°C

• Storage humidity: 35 to 95%RH

• Ambient temperature: -25 … 70°C

• Ambient humidity: 35 to 95%RH

Environment resistance is rated at no freezing or condensation.
