Inductive Sensor M8, PNP NO, Flush – DW-AS-603-M8

Contrinex inductive proximity sensor M8, PNP NO DW-AS-603-M8

Shield (Flush), Embeddable, 1.5 mm Sensing distance, IO-Link

Body

The DW-AS-603-M8 has housing size of M8 and the mounting type is embeddable. This proximity sensor has Stainless-steel V2A housing material and has the enclosure rating IP 67.

Connection

Connection of the DW-AS-603-M8 inductive proximity sensor is via a M12 4-pin connector.

Sensing specifications

The diameter of DW-AS-603-M8 sensing side is 8 mm and the sensing distance for this proximity sensor is 1.5 mm.

Control output

The control output of this M8 inductive proximity sensor is Normally open NO PNP with switching frequency of 5000 Hz and the input for this proximity sensor is 10 to 30 VDC.

Temperature

Ambient operating temperature for DW-AS-603-M8 proximity sensor is from -25 to +70°C and temperature drift is ≤ 10% Sr.

Industries / applications:

Counting parts in a system.

Automatic car washes.

Detection of broken metal parts of various industrial devices.

Detection of elevator door closure.

Car body assembly.

Production of coils and transformers.

Automated industrial processes.

Identify the smallest changes in the gears of metal gears.

Measure and control speed.

Detection and detection of mechanical movements.

Separation of metal parts.

Measurement and calculation of thickness in metal parts.

Measuring and calculating the distance from the parts.

Metal detectors.

Traffic lights and road traffic control.

To detect the presence of an object in a selected program and at the time of inspection.

Conveyor system control.

3 important points in choosing the inductive proximity sensor.

Inductive proximity sensors only detect metal objects.

Strong magnetic fields affect the performance of inductive proximity sensors.
