Inductive Sensor M18, PNP & NPN NO/NC, Flush – PSC1805-NP
DESCRIPTION
Riko proximity sensor M18, NPN & PNP NO/NC – PSC1805-NP
Shielded (flush), Cable type connection, 5 mm Sensing distance
The Riko proximity sensor PSC1805-NP features Special line-out design for bending resistance and tensile. It will upgrade the sensor’s durability and life. This NPN and PNP proximity sensor comes in a round tubular shape, sensing distance of 2mm, sensing side diameter and housing size of m18 and Shielded (flush) installation. The standard cylindrical inductive sensor can be used in diverse applications requiring non-contact detection of metallic objects.
As a quick report, this inductive proximity sensor provides:
- 18 mm sensing side diameter
- NPN NO/NC and PNP NO/NC control output
- 5 mm sensing distance
- Shielded (flush) installation
- IP67 ingress protection structure according to IEC standards
- Special line-out design for bending resistance and tensile
Body
This Riko NPN and PNP proximity sensor features IP67 ingress protection. The sensor’s special line-out design bending resistance and tensile will upgrade the durability and life of it.
Connection
The Riko proximity sensor PSC1805-NP features standard cable type connection with Special line-out design for bending resistance and tensile. This black cable covers the sensor’s 4 wires. It is 2 meters in length, and is made of PVC.
Sensing specifications
This inductive sensor’s sensing side diameter is 18 mm. The maximum distance that this sensor can detect its standard sensing target, which is a 18x18x1 mm piece of iron, is 5 mm. This so-called sensing distance differs from one sensing target to another, based on their material, size, etc.
Although almost no one talks about the setting distance of an inductive sensor, it is a big deal to know this concept. Every sensor can detect its standard sensing target in a specified range, no matter what changes occur in ambient temperature, voltage fluctuations, etc. This distance, which is called the setting distance, is from 0 to 4.0 mm for this proximity sensor.
Control output
The PSC1805-NP features PNP NO/NC and NPN NO/NC control output. PNP stands for Positive-Negative-Positive transistors, and NPN stands for Negative-Positive-Negative transistors.
Temperature
There are limitations in PSC1805-NP NPN and PNP proximity sensor operating temperature. This temperature range is -20 … +60°C.
Industries / applications
- Part detection on industrial conveyor systems
- Automated production lines
