Analog Proximity Sensor M30, Semi-Flush – DW-AD-509-M30
Applications of Contrinex Analog output inductive proximity sensors
- Measuring the thickness of metal parts.
- Measuring the distance of metal parts from the sensor.
- Distinguish small and large parts from each other.
- Sorting and counting on machines.
- Printing machines.
- Machine tool spindle position.
- Position monitoring on grippers and clamps.
DESCRIPTION
Contrinex inductive proximity sensor M30, Analog Voltage/Current DW-AD-509-M30
Shield (flush), Quasi-embeddable, 0 to 20 mm Sensing distance
Body
The DW-AD-509-M30 has housing size of M30 and the mounting type is Quasi-embeddable. This proximity sensor has Chrome-plated brass housing material and has the enclosure rating IP 67.
Connection
Connection of the DW-AD-509-M30 inductive proximity sensor is 2 m cable. This cable material is made of PUR and it is a 4 wire connection.
Sensing specifications
The diameter of DW-AD-509-M30 sensing side is 30 mm and the sensing distance for this proximity sensor is 0 to 20 mm.
Control output
The control output of this inductive current sensor is Voltage/Current with switching frequency of 200 Hz and the input for this proximity sensor is 10 to 30 VDC.
Temperature
Ambient operating temperature for DW-AD-509-M30 proximity sensor is from 0 to +70°C and temperature drift is ≤ 5 % Sd and from -25 to 0°C and temperature drift is ≤ 10 % Sd.
Industries / applications:
- Measuring the thickness of metal parts.
- Measuring the distance of metal parts from the sensor.
- Distinguish small and large parts from each other.
- Sorting and counting on machines.
- Printing machines.
- Machine tool spindle position.
- Position monitoring on grippers and clamps.
- Material handling and automated assembly.
