Analog Proximity Sensor M18, 4 wire, Semi-flush – IS 518-02A

SensoPart Inductive sensor with analog output – IS 518-02A

Quasi-flush, 4-wire, M18 x 50 mm Dimensions

The SensoPart analog proximity sensor IS 518-02A features short-circuit protection (Q) and overload protection protective circuits. This sensor comes in a round cylindrical shape, sensing distance of 0 to 10mm, sensing side diameter and housing size of M18 and quasi-flush installation. The standard cylindrical inductive sensor can be used in diverse applications requiring non-contact detection of metallic objects. The typical inductive sensors can be used in diverse applications requiring detection of metallic objects.

As a quick report, this analog proximity sensor provides:

• M18 x 50 mm Dimensions

• Quasi-flush Mounting

• 10 mm Switching distance

• ≤ 0.3 mm Repeatability

• 0 to 200 Ω Load resistance

• 15 … 30 V DC Operating voltage, +UB

• ≤ 10 mA No-load current, I0

• 1 Switching output

Body

The IS 518-02A has housing size of M18 and the mounting type is Quasi-flush. This proximity sensor has Brass, chrome-pated housing material and has the enclosure rating IP 67.

Connection

Connection of the IS 518-02A analog proximity sensor is cable. This cable is a 4 wire connection.

Sensing specifications

The analog proximity sensor sensing side is M18 and the Switching distance for this proximity sensor is 0 to 10 mm.

Switching output

The switching output of this products is analog (current) and the analog output for this proximity sensor is 0 to 10 V / 4 to 20 mA.

Temperature

Ambient operating temperature for IS 518-02A proximity sensor is from -10 to +60°C.

Industries / applications:

• Robotics

• Assembly and handling

• Factory automation

• Mechanical engineering
